MSI B840M GAMING WIFI6E AM5 mATX Motherboard

MSI B840M GAMING WIFI6E AM5 mATX Motherboard
MSI B840M GAMING WIFI6E AM5 mATX Motherboard
  • Regular Price:  TK 19,400
  • Product id:  217
  • Stock: In Stock
  • Model: B840M GAMING WIFI6E
Based on 0 reviews. - Write a review
TK 19,400
Ex Tax: TK 19,400
Add To Cart
Buy Now Add to Compare
Add to Wish List Compare this Product

Key Features

  • Supported CPU: Ryzen 9000/ 8000/ 7000 Series Processors for Socket AM5
  • Supported RAM: 2x DDR5, up to 8000 (OC) MT/s
  • Graphics Output: 1x HDMI, 1x DisplayPort
  • Features: Realtek 8125D 2.5G LAN, Wi-Fi 6E, Bluetooth 5.3
View more info
Specification
Basic Information
BIOS Flash BIOS Button
Chipset AMD B840
Form Factor mATX 226mmx243.84mm
Supported CPU Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Audio Realtek ALC897 Codec 7.1-Channel High Definition Audio
Expansion Slots
M.2 Socket 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
PCI 2x PCI-E x16 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset) PCI_E1 slot Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor)
Graphics
Graphics 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz
Memory
Slots 2 x UDIMM
Supported Memory Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8000+ MT/s 1DPC 2R Max speed up to 7200+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only
Type DDR5
Maximum Memory 128GB
Connector & Ports
Audio 1x Front Audio (JAUD)
HDMI 1x HDMI 2.1
Internal I/O Ports 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports
LAN Port (s) Realtek 8125D 2.5G LAN
Supported Storage 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0)
USB (s) 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front)
Display Ports (s) 1x DisplayPort 1.4
Wireless Communication module Wi-Fi 6E Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3, FIPS, FISMA
RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Other Features
Special Features 4x EZ Debug LED 1x EZ Memory Detection LED
Warranty Details
Warranty 3 Years Warranty
Description

MSI B840M GAMING WIFI6E AM5 mATX Motherboard

The MSI B840M GAMING WIFI6E AM5 mATX Motherboard is designed to deliver next-level gaming performance and stability for modern PCs. It supports the latest AMD Ryzen 7000 Series processors on the AM5 socket, offering future-ready performance for gamers and content creators. With dual-channel DDR5 memory support up to 7200+ MHz (OC), users can enjoy ultra-fast speeds and improved responsiveness.

Equipped with PCIe 4.0 slots and Lightning Gen 4 M.2 storage, this board ensures faster data transfer and reduced game loading times. The Wi-Fi 6E and 2.5G LAN provide seamless and low-latency connectivity, perfect for online gaming and streaming.

Its extended heatsink design, high-quality VRM, and multiple fan headers ensure reliable cooling even under heavy workloads. Enhanced with Audio Boost for crystal-clear sound and Steel Armor PCIe slots for GPU protection, the MSI B840M is built for durability and immersive gaming.

Compact yet powerful, the MSI B840M GAMING WIFI6E is a perfect choice for building a high-performance gaming PC.

Buy the MSI B840M GAMING WIFI6E AM5 mATX Motherboard at the best price in Bangladesh from Tech Heaven IT. We offer 100% authentic MSI motherboards with 3 Years Official Warranty. Order online or visit Tech Heaven IT today to get your gaming motherboard at the best deal.
