MSI H310M Pro-M2 Intel 9th Gen Motherboard

Save: 1000৳

MSI H310M Pro-M2 Intel 9th Gen Motherboard

Price: TK 10,300
Regular Price: TK 11,300
Product id: 189
Stock: In Stock
Brand: MSI
Model: MSI H310M Pro-M2

Based on 0 reviews. - Write a review

TK 10,300

TK 11,300

Ex Tax: TK 10,300

Qty

Add To Cart

Buy Now Add to Compare

Add to Wish List Compare this Product

Key Features

Supports 9th/8th Gen Intel Core/Pentium Gold/Celeron processors for LGA 1151 socket
Supports DDR4 Memory, up to 2666 MHz
Graphics Output: 1x HDMI, 1x DVI, 1x VGA
Features: Realtek ALC887 Codec, 1 x M.2 slot (Key M)

View more info

Specification

Basic Information
Chipset	Intel H310 Chipset
Form Factor	m-ATX Form Factor 9.1 in. x 7.3 in. (23.0 cm x 18.5 cm)
Supported CPU	Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket
Audio	7.1-Channel High Definition Audio
Expansion Slots
M.2 Socket	1 x M.2 slot (Key M) Support up to PCIe 2.0 x4 and SATA 6Gb/s Supports 2242/ 2260 /2280 storage devices
PCI	1 x PCIe 3.0 x16 slot 2 x PCIe 2.0 x1 slots
Graphics
Graphics	1x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz 1x HDMI port 1.4, supports a maximum resolution of 4096x2160@30Hz Connector & Ports
Memory
Slots	2 x DDR4 memory slots
Supported Memory	Supports DDR4 2666/ 2400/ 2133 MHz
Type	Dual channel memory architecture Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP)
Maximum Memory	32GB
Connector & Ports
Audio	Realtek ALC887 Codec 7.1-Channel High Definition Audio
DVI-D (s)	1x DVI-D port, supports a maximum resolution of 1920x1200@60H
HDMI	1x HDMI port 1.4, supports a maximum resolution of 4096x2160@30Hz
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper
LAN Port (s)	1 x Intel I219-V Gigabit LAN controller
Supported Storage	4 x SATA 6Gb/s ports 1 x M.2 slot (Key M) Support up to PCIe 2.0 x4 and SATA 6Gb/s Supports 2242/ 2260 /2280 storage devices
TPM (Trusted Platform Module )	1 x TPM module connector
USB (s)	Intel H310 Chipset 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors) 6 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connectors)
VGA (s)	1x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
Warranty Details
Warranty	03 years Warranty

Description

MSI H310M Pro-M2 Intel 9th Gen Motherboard

The MSI H310M Pro-M2 Intel 9th Gen Motherboard is a budget-friendly yet powerful motherboard designed for smooth and reliable PC performance. It supports both Intel 9th and 8th Gen Core, Pentium Gold, and Celeron processors with the LGA 1151 socket, making it a flexible choice for building home, office, or entry-level gaming PCs.

This motherboard comes with dual-channel DDR4 slots supporting up to 32GB RAM at 2666MHz, ensuring stable multitasking and faster system response. For visuals, the H310M Pro-M2 features HDMI, DVI-D, and VGA outputs, with support for 4K resolution at 30Hz, delivering sharp and clear display output for work and entertainment.

In terms of storage, it includes an M.2 slot for NVMe SSDs and four SATA 6Gb/s ports, giving you multiple options to expand your storage system. The built-in Realtek ALC887 audio codec provides immersive 7.1-channel HD sound, while Intel Gigabit LAN ensures a fast and stable network connection.

With its Micro-ATX form factor, the MSI H310M Pro-M2 easily fits into most PC cases, making it a practical and affordable choice for those looking to build a dependable system without compromising performance.
